Shot-Activated Recording Yes
Max. Recoil 1000 g/0.4 ms
Frame Rate 25 Hz
Ballistic calculator Yes
Detection Range 3100 m
Palettes Black Hot, White Hot, Red Hot, Fusion, Red Monochrome, Green Monochrome
Dimensions 452 × 95 × 80 mm (17.8 × 3.7 × 3.2 in)
Exit Pupil Diameter 6 mm
Pixel Interval 12 μm
Distance Measurement Yes
Picture In Picture Mode (PIP) Yes
Hotspot Yes
Audio Recording Yes
Magnification 2.5× – 28× Support 0.5× step value of continuous zooming
Image sensor VOx Uncooled Focal Plane Arrays
Response Waveband 8 μm to 14 μm
FFC (Flat Field Correction) Auto, Semi-Auto, Manual
Standby Mode Yes
Resolution 1280×1024
Lens system 60 mm, F1.0
NETD Less than 18 mK (@25°C, F#=1.0)
Mounting Standard 30 mm
Field of view (H × X) 14.6°×11.7°/25.6 m×20.5 m
Diopter adjustment range -4D to 4D
Focusing range 6 m minimal
Hot Track Yes
Eye relief 45 mm
Display 2560x2560, 1.03 inch OLED
Storage Built-in EMMC (64 GB)
Record Video On-board Video Recording
Capture Snapshot Yes
Battery Type Two rechargeable Lithium batteries (internal), one replaceable and rechargeable 18650 battery (external)
Battery Operating Time 9 hours continuous running (@25°C, LRF on)
Power supply 5 V DC/2 A, USB Type-C interface, Supports QC3.0 (* Only the built-in battery will be charged via the type-C cable. Use the battery charger to charge the external battery)
Operating Temperature Range -30 °C to 55 °C (-22 °F to 131°F)
Weight 1.0 kg ( 2.2 lb)
Protection Level IP67
